疊螺污泥濃縮機

疊螺污泥濃縮機繼承了疊螺污泥脫水機的低能耗，高效率，全自動控制，運行穩定等技術優點，可直接將二沉池污混快速續濃縮，且濃縮分離后的污泥濃度在90%~96%范圍內穩定可調，采用該設備后無需建設濃縮池，減少建設投資和占地，有效減少濃縮池污泥造成的惡臭和磷釋放，降低后續處理的工作負擔，并大幅度提高污泥脫水和深度脫水設備的產能。

Sludge thickening screw press inherits the technical advantages of sludge dewatering screw press and developed its own advantages, such as low energy consumption, nigh efficiency, fully automatic control, and stable operation. It can directly thickenthe sludge in the secondary sedimentation tank quickly and continuously, and the sludge concentration is stable and adjustable in the range of 90-96%. After using tinis equiprient, thickening tark is not needed any more, which reduces construction ost and land space. Furthermore, it can effectively reduce the odor and phosphcorus release caused by the sludge in the thickening tank, release the workload of subsequent treatments, and significantly increase the capacity of sludge dewatering equipment.

設備原理

Work Principle

疊螺污泥濃縮機由濃縮主體、驅動裝置、濾液槽、混合系統、架體等組成。疊螺污泥濃縮機工作時，通過污泥泵將污泥提升至混合槽后，此時，加藥泵也定量地對混合精輸送藥液，微樣電機帶動整個攪拌系統將污泥與藥液進行充分混合，從而產生礬花，當液位達到液位傳感器得到信號，使得疊螺主體電機工作，從而開始壓濾流入至疊螺主體內污泥，在螺旋軸的作用下，將污泥一步一步提升至污泥出口，滿液則從固定環和游動環之間的間隙中流出來。

總的來說，疊螺污泥濃縮機是運用了螺桿擠壓原理，通過螺桿直徑和螺距變化產生的強大擠壓力，以及游動環與固定環之間的微小縫隙，實現對污泥進行擠壓濃縮的一種新型的固液分離設備。

The sludge thickening screw press is composed of a thickener, a driving device, a filttate tank, a mixing system, and a frame. When the screw press is working, the sludge IS purnped to Ihe rousing tark by the sudge purmp, In the mean time, the dosng pumQ aiso guanttatively transports the polmer to the mixing tank, then the stirrina motor drives agitator to start mixing untl solid particles are floculated. When the liquid level reaches the upper level of the fiquid level sensor, the sersor gets a sigrwl and instructs the main motor of screw press to work, thereby starting to filter and press the sludge that comes into the screws body. Under the squeezing of the screw shaft, the sludge is raised step by step to the sludge outlet, and the filtrate flows out from the gap between the fixed ring and the moving ring.

In general the sludge thickener screw press uses the principle of screw extrusion which is finalized by the strong extrusion force from the change of screw diameter and pitch, and the tiny gap between the rroving ring and the fixed ring, thus the sold andliguid can be separated. Sluckenthickening screw press is a new type of solick-licuid separationequipment for sludge concentration.

技術特點

TechnicalFeatures

污泥濃縮范圍廣，適用污泥含水率范圍98%~99.8%濃縮后污泥含水率在90%~96%的范圍內穩定可調濃縮效率高，占地面積小

無濾布、自清洗、無堵塞、無需高壓板沖洗水低速運轉，低能耗，運行成本低，無震動，無噪音封閉式作業，減少臭氣產生

易損部件少，維修成本低，使用壽命長全自動控制，連續運行、維護管理簡單。

The sludge thickening range is wide, it is applicable to sludge consistency ranges from 98% to 99.8%. The concentrate of the thickened sludge is stable and adjustable in the range of 90-96%. High concentration efficiency and small land space. No filter cloth, self-cleaning, no clogging, no need for high-pressure washing water.

Low speed operation, low energy consumption, low operating cost, no vibration, no noise.

Closed operation reduces odor emissions.

Few vulnerable parts, low maintenance cost and long service life. Fully automatic control, continuous operation, simple maintenance and management.

使用范圍

Scope of application

作為污泥深度脫水系統的預處理設備，為隔膜壓濾機等污泥深度脫水設備配套替代污泥濃縮池，作為污泥脫水系統的預處理設備用于其他濃縮或固液分離工藝

As the pretreatment equipment of the sludge deep dewateering system, it is usually matched with ultra-high pressure elastic press, membrane filter press and other sludge deep dewatering equipments.

Replace the sludge thickening tank as the pretreatment equipment of the sludge dewatering system. Used in other slurry concentration or solid-liquid separation processes.
